Cummins 40kw Diesel Generator, Cummins Generator For Philippines, Cummins Silent Generator, Cummins Dg Set, Denyo Canopy Design
Generator Standard Compose:
- Dongfeng Cummins Engine, model 4BT3.9-G2.
- Meet the environmental temperature 40 ℃ water tank radiator, Driving belt cooling fans, with fan safety shield
- 24 V charging generators
- Generator: Single bearing generator, IP23 Grading Protection, H Insulation degree
- Shock absorber
- Dry air filter, Fuel filter, Oil filter
- Power output ABB circuit breaker
- Standard control panel
- 12 V battery and battery connection cables
- Battery Charger
- Exhaust pipe, Bellows, Flange, Muffler set
- Documents and Manuals
Specification of Cummins Gen-Set:
| Generator Set Specification |
| Model | A-C50H |
| Max. Power | kVA | 50 |
| kW | 40 |
| Rate Power | kVA | 45 |
| kW | 36 |
| Frequency | Hz | 60 |
| Rate Voltage | V | 220/127 |
| Rate Current | A | 118.1 |
| Dimension For Open-type Genset | mm | 1780 X 750 X 1050 |
| Weight For Open-type Genset | kg | 2300 X 900 X 1250 |
| Dimension For Soundproof Genset | mm | 70 |
| Weight For Soundproof Generator | kg | 1430 |
| Engine Brand | Cummins |
| Engine Model | 4BT3.9G2 |
| No. of Cylinder | 4 Cylinder in line |
| Aspiration | | Turbocarged |
| Governor | Electric |
| Engine Max. Output Power | kW | 44 |
| Displacement | L | 3.9 |
| Starting Voltage | V | 24 |
| Bore | mm | 102 |
| Stroke | mm | 120 |
| Lubrication Oil Capacity | L | 11 |
| Alternator Specification |
| Alternator Manufacturer | Cummins Generator Technologies |
| Alternator Model | PI 144H |
| Alternator Brand | Stamford |
| Rate Output | kVA | 42 |
| Frequency | Hz | 60Hz |
| Altitude | M | ≤1000 |
| Insulation | Class H |
| Voltage Regulation | AVR Model SX460 |
| Protection Grade | IP23 |
| Alternator for optional | Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional |
| Control Panel Specification |
| Controller Brand | Deepsea |
| Controller Model | DSE7320 |
| Breaker Brand | Delixi |
| Breaker Capacity | 80A |
| Battery Charger | Supply |
| Emergency Stop Button | Supply |
| Automatic Mains Fail (AMF) | Supply |
| The control panel supply the full protection with Alarm and Shutdown of the diesel generator include High Temp, Low Oil Pressure, Over / Under Speed, Over Load, Start / Stop Fail, Under / Over Voltage etc. |
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller. |
Why Choose Hosem Power Generator?
Reasons1: We are More Professional
Most members of Hosem Power have more than 10 years of experience in the generator area, Our mechanical engineers, electrical engineers have more than 20 years of experience in the generator ara. We are always ready to serve to your needs.
Reasons2: Outstanding Quality
Our advantage lies in:
1. Good shock absorption performance: Optimal design of shock absorption system based on computer dynamic simulation.
2. Advanced control system: Full monitoring system control strategy found on reliability design.
3. Low noise: Tailor custom-engineered exhaust silencer system for each set.
4. Green environmental protection: Diesel generator set combined energy-saving and low emission in one.
Reasons3: Strictly QC Before EX-Factory.
Each and every unit is strictly factory tested before shipment.
1) Parts faults testing
2) Fuel tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insulation testing
6) Noise testing
7) Loading Testing: 25%, 50%, 75%, 100%, 110% load to check verify that all control systems, alarm and shut-down protection.
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy, Or 100% irrevocable L/C at sight.
Q: What is your lead time?
A: About 20-30 days after receiving advance deposit or original L/C.
Q: What certificates do you have?
A: We have CE, ISO. And we can apply for specific certificates for different countries such as SONCAP for Nigeria, COI for Iran, SASO for Saudi Arabia, etc.
Q: What warranty do you provide?
A: One year, during the guarantee period, we will supply free of the easily damaged parts for the possible problems except for the incorrect operation. After expiration, we supply cost spare parts for Genset maintenance.
Product Tags:
|
|
ISO 9001 Standby 50kVA Cummins 40kW Diesel Generator Images
|
